Modco designs and manufacturers a variety of VCO's

Modco’s latest addition to its line of broad band low Phase Noise VCO’s is model MD1200-1700MST. The unit tunes 1200MHz to 1700MHz in 0.5V to 12.0V. Phase Noise is -105dBc @ 10kHz offset. Low Profile package size is 0.500 X .500 X 0.125 inch.

Model LVC402-406VS tunes 401MHz to 406MHz and is used in MedRadio applications. A bias voltage of 1.5V delivers + 2.0dBm power with only 5ma current consumption. Phase noise is -98dBc @ 10kHz offset. Package size is 0.175 inch square with height of .075 inch

Recent Additions to the Modco Product Line Up

Voltage Controlled Oscillators

LVC Series VCO’s: Ideal for battery powered wireless applications. They require only 1.5V bias and draw just 5mA. The package size 0.175 inch square and height of 0.075 inch.

MX Series VCO’s: Very Low Phase Noise VCO's with the added functionality of a modulation port for increased design flexibility and reduced part count. Modulation sensitivity is typically a negative slope of 20kHz to 40kHz.

MCS Series VCO’s: The worlds smallest CRO. Lowest Phase Noise VCO’s in a 0.3 inch square package

MCR Series VCO’s:Provides the ultimate in low Phase Noise performance. CRO designs available for frequencies from 825MHz to 7820MHz. Industry standard 0.5 inch square package. Low profile 0.125 inch height are available on select models.

MD Series VCO’s: Very low Phase Noise low profile Strip-line design in 0.5 inch square package. Designs available from 100MHz to 2490MHz.

MF Series VCO’s: Very low Phase Noise Micro-strip line design offered in a variety of packages. Incorporates an internal buffer amplifier.

MFH Series Hermetically Sealed VCO’s: Very low Phase Noise with internal buffer amplifier.

FL Series VCO: Worlds smallest VCO  in a 0.175 inch package. Available up to 12GHz.
